Affordable Pneumatic Driven L Bar Sealing Machine and Shrink Tunnel Wrapping Machine

FOB Reference Price:Get Latest Price
$3,500.00 - $4,500.00 / Unit | 1 Unit/Units (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Packaging Type:
Case
Packaging Material:
Plywood
Type:
Wrapping Machine
Condition:
New
Place of Origin:
Fujian, China
Brand Name:
Sheng Zhou
Model Number:
SZ SW5545P
Power:
13 kw
Voltage:
380 v, 50 hz, 3 ph
Application:
Food, Textiles
Weight:
250 kgs
Automatic Grade:
Automatic
Certification:
CE Certificate
Driven Type:
Electric & Pneumatic
Dimension(L*W*H):
3560x800x1500 mm
Shrink Film:
Centerfold POF , PE, PVC
Accept Product Length:
450 mm (18")
Accept Product Width:
400 mm (16")
Accept Product Height:
250 mm (10")
Working Speed:
15 packs per minute
Structure:
Welded tubular steel frame
Compressed Air:
6 bar
Conveyor:
Variable speed
Warranty:
1 year
Customized Model:
On request
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
20 Unit/Units per Month
Packaging & Delivery
Packaging Details
Plywood case
Port
Xiamen
Lead Time :
7 days




Benefits

1. Working speed up to 15 packs per minute



2. Extremely versatile for low capacity or random packing needs



3. Achieves perfect shrink wrap package at very affordable price



4. Incorporated by one pneumatic driven L Bar Sealing Machine and one Hot Air Convection Shrink Tunnel, both machines can be separated and work alone when necessary





Product Description

Features



Sealing Arm

  • Pneumatic driven electromagnetic clamp, timer or button control

Film Cradle

  • Quick change design to accepts different sized rolls of film

Product Loading Table

  • Adjustable by wheel, available in baking varnish or stainless steel

Discharge Conveyor

  • Variable speed, takes away package after sealing process

Perforator Roller

  • Evacuates air from sealed package and eliminates "pillowing effect" from heat shrinking process

Low Voltage Impulse Sealing System

  • Provides consistently strong seals and superior operator safety

Hot Air Circulation System

  • 30% power saving

Digital-indicate Thermal Controller

  • Adjusts heating by 1oC for accurate heating control

Heavy Duty Lock Casters

  • Easy relocation at any working place



Applications



Tobacco ConfectioneryTea and Coffee
DVD and SoftwareCosmeticPharmaceutical
Paper & BookFoodMedia & Magazine
LaundryBeverage...





Specifications



ModelSZ SW5545P
Shrink FilmCenterfold POF, PVC, PE
Accept Product, LengthUp to 450 mm (18")
Accept Product, WidthUp to 400 mm (16")
Accept Product, HeightUp to 250 mm (10")
Working Speed15 packs per minute depends on operator's skill
Compressed Air6 bar
Electrical380 v, 50 hz, 3 ph
Power Consumption13 kw
Overall DimensionL 3,560 x W 800 x H 1,500 mm (141" x 32" x 59")














About Us

In the 1990’s, Shenzhou started business with a 3-staff store selling Adhesive Tapes, PP Straps, Stretch Film and Manual Strapping Tools. After 20 years’ growth, we are proud to have a 50-staff family running a 1,200 square meters factory with annual revenue 0.7 million US dollars.



Now, Shenzhou Packing Machine Co., Ltd. is well recognized both in China and international markets as a reputable manufacturer supplying quality Infrared Shrink Tunnel, Steam Shrink Tunnel and Fully Automatic Shrink Wrapping Machine.



In addition, being an authorized distributor of several successful brands, we introduce top quality Made-in-China packing machines to buyers & users in the world wide who look for Carton Automation System, Cellophane Wrapping Machine, Thermal Transfer Coder and Pallet Stretch Wrapping Machine.



With Shenzhou, you have a large choice in packing machines that meet your requirements. Giving your trust, we return our affordable packing solution, trouble-free machine, professional service and trustworthy partnership.



You can always rely on Shenzhou, a young and dynamic partner when you need packaging solution.








Warranty

Shenzhou warrants all packing machines of its manufacture to be free from defects in material or workmanship for a period of one (1) year from the date of shipment, provided

1 Given normal and proper usage,

2 Owned by the original buyer,

3 Operated in accordance with generally approved practice and Shenzhou’s instructions,

4 No repairs, modifications, or replacements made by others without Shenzhou’s prior written approval.



Shenzhou repair components are supplied free of charge during the warranty period. Shenzhou personnel are available for equipment training, either on-site/hands-on or in a classroom environment, supported by visual aids and literature, to be contracted for by a separate purchase order.







FAQ

Q: How can I know your Shrink Wrapping Machines produce packages in the exact same way I need?

A: We always encourage clients to send their samples to be tested on my machines. Video and pictures will be sent back to show how my machine works on your product and how your product looks like after contract operation. We help you to understand clearly what our machine can do, before you make final decision.



Q: Can you build your Shrink Wrapping Machines to meet my special requirement?

A: Yes, thanks to the dedicated R&D team, customized model is always available in accordance with your specific requirement.



Q: Do you test all your Shrink Wrapping Machines before delivery?

A: Yes, we have 100% test before delivery.



Q: What is your warranty on your Shrink Wrapping Machines?

A: We offer 1 year warranty on ALL machines.



Q: How about your delivery time?

A: 20 days upon your advance payment. Actually we do effect prompt delivery within 3 working days when we have your machine in stock.



Q: Is your price the lowest in the market?

A: We are not going to guarantee you a cheapest machine when you compare prices among suppliers. However, at the price you accept, we do promise you a most reliable & affordable Shrink Wrapping Machine as well as profitable & trouble-free business.
